$0.00
Part No.: IH-RWCS
Size Available: DN50 to DN1200
Temperature: -30°C / + 70°C
Notes:
Max Liner thickness: Gauged by flange pattern
Max Working Pressure: Determined by construction and fitting/flange design
No Bend radius: advised for non wire reinforced hose
Lengths: Can be made up to 10 meters
Colour: Black
Tube: NR/BR blend Super Abrasion Resistant Rubber
Cover: Abrasion, UV and Ozone resistant rubber
Reinforcement: Synthetic fabric
Use: Slurry and water transfer, dewatering and tailings pipelines as well as transfer of chemicals, hydrocarbons and acids.
End connections: Plain end, Flanged (fixed or swivel), Flanged full spigot (fixed or swivel), Double flanged, Grooved (roll or cut), Threaded, Butt weld, Custom
| Size | 2", 3", 4", 5", 6", 8", 10", 12", 14", 16", 18", 20", 22", 24", 26", 28", 30", 32", 36", 40", 44", 48" |
|---|---|
| Max Working Pressure kPa | 1000 kPa, 1500 kPa, 1800 kPa, 2000 kPa, 2500 kPa, 3000 kPa, 3500 kPa, 4000 kPa, 5000 kPa, 6000 kPa |
| Max Temperature | 70°c |
| Min Temperature | -30°c |
